FF DataFactory 4.0.0
Release overview:
New Features & Improvements
• Health Monitoring Enhancements: Added notification handling via UI and email
alerts for designated recipients.
• SEARCH Page: Searching by Brand or Color is now accompanied with the
related icon.
Integration & API Updates
• HxGN dC3 Video fully integrated
• Event API extended with:
o /api/camera/events/upload/generate-base64 - Uploads a camera
event along with an associated image, then generates an event with
a Base64-encoded image for subscribers.
o /api/camera/events/upload-base64 - Uploads a camera event
along with an associated image encoded in Base64 format.
• JSON Protocol Update: Added new sorama field containing additional
metadata (video clip, sound overlay, license plate, etc.)
• Additional exception/error handling for Milestone SDK during connection
Business logics related
• Camera management: Added CAMMRA AI support, UI fixes applied.
• Offline Activation: Stability fixes applied.
• MQTT: GET and POST modifications — each cameraEvent now includes a
unique UUID in <CAMERA_LPR_ID> tag.
• Event proxy: Added Base64 support allowing user to choose the format
(Base64 or Multipart) for event transmission.
• Illegal stop: PDF_export widget issue fixed.
• Loud vehicle detection (Sorama):
o Added feature: video playback with sound visualization details
o UI enhancements
• Multitenant parking – New business logic allowing to manage parking lot with
multiple tenants simultaneously.
• DF Clustered – .pdf export issue in Cluster Mode resolved.
• Camera Health simple – added notification handling via UI and email alerts for
the designated recipients.
• HxGN dC3 Video (CPU version): ROI frame widget improved with enhanced
control features. Stability issues fixed. LPR/MMR library updated
Issue Fixes / Features added
• CHART Page: Display reliability improvements.
• Milestone Plugin installer: Implemented fix for successful installation of
separate plugin components.
• BL Event Queue Handling: DF now automatically manages a overflowing queue
of unprocessed events, eliminating the need to manually kill the Map Processor
Windows process.
• Enhanced displaying on SEARCH and EVENTS pages of:
o Vehicle crops
o Plate crops in table mode.
• Milestone Integration:
o Fixed video playback issues.
o Smart Client connection stability issues.
• SEARCH page: Vehicle Make icons are displayed correctly.
• Solved network connectivity issues with RTSP streams, including automatic
decoder restarts and expanded logging for transport connection error
• Burger menu auto-hide now
• Extended incoming event handling logic for invalid vehicle bound-box
coordinates
