SD card recommendations

SD card recommendations

CAMMRA stores image data based on the type of crop configuration selected. The storage requirement per event depends on whether the system is saving:

  • Only License Plate (LP) crops

  • Vehicle crops (which include LP crops)

  • Full Frame images (which also include LP crops)

CAMMRA image sizes can vary significantly due to:

  • Lighting conditions

  • Scene complexity

  • JPEG compression quality

  • Motion or blur in the frame

SD Card usage

(Assumes maximum file sizes: LP = 10 KB, Vehicle = 370 KB, Full Frame = 550 KB)


SD Card Size

Usable Space

Vehicle Crop Events

Full Frame Events

8 GB

~7.5 GB

~20,250

~13,600

16 GB

~15 GB

~40,500

~27,200

32 GB

~30 GB

~81,000

~54,500

Note: max. database size in CAMMRA is 100.000 events

To ensure reliable performance always reserve SD CARD space based on chosen image type configuration.

The tables consider the growing database size, ensuring safe and realistic planning for CAMMRA long-term operation.

Continuous video recording can consume several gigabytes of SD card space, potentially leaving less or no room for CAMMRA to store event images and database entries.

​
​
