Direct integration

Direct integration section is dedicated to integrations to 3rd party systems, which requires sending in different format / protocol, than CAMMRA AI provides on its own.

CAMMRA AI configuration for Genetec Security Center integration:

For to configure CAMMRA AI sending data to Genetec via 3rd party ALPR plugin:

1. Go to Direct integration and choose Genetec from the drop-down menu.

2. Fill url https://<hostname>/api/v1/lpr/LprIngestion/reads

Then choose any Camera ID name and user’s credentials.

In Genetec integration it’s not possible to choose the event type. CAMMRA AI sends lost events only.

3. Toggle Turn On button to the right to Enable integration.

4. Use HTTPS and make sure to switch  On Self-signed in the Settings >  Security section.

​

​

5. In Settings > Image settings > Screenshot to save > Frame type choose the type of image which will be displayed in Security Desk as a part of read. Standard content of every read is text form of the License plate, date and time information and License plate crop. It is recommended to add Full frame or Downsized frame image to have a context view.

For to get instructions how to setup this integration on Genetec side, follow-up this instruction (it works the same as for CAMMRA)

2N IP Base Intercom integration:

​

To configure sending data to 2N via 3rd party ALPR plugin, go to Direct integration and choose 2N IP device from the drop-down menu.

​

Step 1. Specify the URL IP address of your 2N device, use HTTPS and make sure to switch  On Self-signed in the Settings >  Security section.

Step 2. Choose Barrier is used for Entry or Exit

Step 4 Enter user name and password of your 2N device

Step 5. Choose direction  IN, OUT or ANY

Step 6. Enable and save the config.

If integration is properly configured, in 2N you should see something like this:
